Tools - Drilling Machine

Drilling Machine - 110 volt or 240 volt

It is essential, when drilling with an Auger to create holes or slots, that a drilling machine with the following minimum requirements is available;

Drilling machine with Auger in a part drilled slot for a Beam Upgrade (modified flitch)

  1. 1000 watts
  2. Reversible
  3. Low speed range down to 150 rpm or less
  4. Speed dial to limit trigger maximum
  5. Trigger soft start
  6. Light in weight
  7. Short body
  8. Overheating cut-out

Buy or Hire a suitable machine from us.

Boring machine with Auger in a part drilled hole, manufacturing a large Timber Resin Splice beam kit

Go Direct to Order Form

Example of drilling with Augers - reinforcement of large decayed beam

Augers

A Manor House carrier beam at first floor level had suffered from Wet Rot and Death Watch Beetle over many years, resulting in loss of strength extending from the bearing end. By careful placing of epoxy coated steel re-bar (BS4449) to our Design the loss of long grain strength could be made up with multiple connectors, the Structural Epoxy Pouring Grout then completing the composite, reinforced repair structure.

Augers are available up to 600mm in length in the following diameters;

10mm, 12mm, 16mm, 20mm, 22mm, 25mm and 32mm

Specials - can be made to virtually any size

Complex beam repair awaiting pouring of Grout

Example of drilling with 3D Cutter - repair of a Joist End

3D Cutters

The joist ends above an occupied flat were badly affected by Dry Rot.. These were replaced with TYPE C Timber-Resin Splice Units which consist of new, pre-manufactured timbers to match the original, with pre-bonded epoxy coated steel re-bar connectors. The slots have been cut with a 3D Cutter - available in 110mm and 250mm working lengths. The pouring resin here is in a two pack, 1 litre pot, for small repairs.

3D Cutters are available in two working lengths - 110mm and 250mm, in the following diameters;

15mm, 20mm, 25mm, 32mm

Joist end Timber-Resin Splice repair during pouring

Go Direct to Order Form


Other tools and accessories

TOOLS

Complete Tool Kit - Augers, 3D Cutters, Chisels, etc. - Hire/week £25.00
Metabo Drilling Machine - low speed, reversible, - Hire/week £35.00
3D Cutter - 25mm x 110mm (EWL) x 1 £21.29
3D Cutter - 25mm x 250mm (EWL) x 1 (extended shaft) £38.50
Matched Auger Set (3) for 20mm bars £60.85
Chisel for slot clearance - all steel 14 inch x 30mm £19.87
Auger Extension - adds 200mm £17.98
Staple Gun - for shutter fixing £34.67
Pallet knife - square edged, stiff, for resin mixing £7.14
Vinyl Gloves - Box of 100 x 1 £9.92
Paper Towel Roll - for clean up of tools £15.65

STRUCTURAL CALCULATIONS, GUARANTEE, CARRIAGE

Structural Check Calculation - proves beam repair = strength £50.00/size
Full Structural Calculation - proves beam/repair = actual load by qualified independent Structural Engineer £150.00/end
Manufacturers Guarantee Certificate - per job £32.50
